HOME 【S】SIDE BEVEL RULE Leather, Synthetic leather

Cutting Rules

Leather, Synthetic leather

Our Recommendation
Type SG、Type GR、 Type S、Type HSG、Type H

Applications
・car seat
・Sporting goods
・Accessories

Material
・PVC
・PU
・TPU
・TPO

Characteristics
・PVC leather: Hardens easily and becomes brittle
・PU leather: no abrasion resistance
・Genuine leather: high elasticity
Share:
type S

Type S - Side Bevel Rule

・Straight cutting surface and precise cutting point.
・Suitable for thick materials.

Applications:
Sticky Notes, Leathers, EVA, EPE, Puzzles and Facial Masks

Super Ground Rule

TYPE SG
Bevel type CB (Center bevel) , LCB (Long center bevel)
Thickness 0.53mm (1.5pt)、0.71mm (2pt)、1.06mm (3pt)
Height 23.60mm (.929"),  23.80mm (.937")
Angle ∠42°、52°
Body hardness HV320,340,380,400,450 / HRC32,34,38,40,45
Edge hardness HV600,640,670,700 / HRC55,58,59,60


Ground Rule

TYPE GR
Bevel type CB (Center bevel) , LCB (Long center bevel)
Thickness 0.45mm (1.27pt)、0.53mm (1.5pt)、0.71mm (2pt)、1.06mm (3pt)、1.42mm (4pt)
Height 23.60mm (.929"),  23.80mm (.937")
Angle ∠42°、52°
Body hardness HV320,340,380,400 / HRC32,34,38,40
Edge hardness HV600,640,670,700 / HRC55,58,59,60


Side Bevel Rule

TYPE S
Bevel type SB (Side bevel) , LSB (Long Side bevel)
Thickness 0.71mm (2pt)、1.06mm (3pt)、1.42mm (4pt)
Height 23.60mm (.929"),  23.80mm (.937")
Angle ∠42°、51°、52°
Body hardness HV320,340,380,400,450 / HRC32,34,38,40,45
Edge hardness HV600,640,670,700 / HRC55,58,59,60


High Rule with Superfine Ground Bevel

TYPE HSG
Bevel type CB (Center bevel) , LCB (Long center bevel)
Thickness 0.71mm (2pt)、1.06mm (3pt)
Height 30mm (1.181"),  32mm (1.26"),  35mm (1.377"),  40mm (1.574"),  50mm(1.968")
Angle ∠42°、52°
Body hardness HV320,340,380,400 / HRC32,34,38,40
Edge hardness HV600,640,670,700 / HRC55,58,59,60


Hight Rule

TYPE H
Bevel type CB (Center bevel) , LCB (Long center bevel)
Thickness 0.71mm (2pt)、1.06mm (3pt)、1.42mm (4pt)
Height 30mm (1.181"),  32mm (1.26"),  35mm (1.377"),  40mm (1.574"),  50mm(1.968")
Angle ∠42°、52°
Body hardness HV320,340,380,400 / HRC32,34,38,40
Edge hardness HV600,640,670,700 / HRC55,58,59,60
