Cutting Rules
Medical box, Luxury Cosmetic box
Our Recommendation
Type SG、Type F、Type S、Type E
Characteristics
Packaging for pharmaceutical products manufactured in clean rooms must be free of burrs and have clean cut edges.
Type SG、Type F、Type S、Type E
Characteristics
Packaging for pharmaceutical products manufactured in clean rooms must be free of burrs and have clean cut edges.
Type E - Creasing Rule
・Excellent radius profile.
・Very smooth creasing head.
・Minimum height tolerance.
Applications:
Packaging Containers, Plastic Boxes and Blisters.
・Very smooth creasing head.
・Minimum height tolerance.
Applications:
Packaging Containers, Plastic Boxes and Blisters.
Super Ground Rule |
TYPE | SG |
---|---|
Bevel type | CB (Center bevel) , LCB (Long center bevel) |
Thickness | 0.53mm (1.5pt)、0.71mm (2pt)、1.06mm (3pt) |
Height | 23.60mm (.929"), 23.80mm (.937") |
Angle | ∠42°、52° |
Body hardness | HV320,340,380,400,450 / HRC32,34,38,40,45 |
Edge hardness | HV600,640,670,700 / HRC55,58,59,60 |
Infinity Cut |
TYPE | F |
---|---|
Bevel type | CB (Center bevel) / LCB (Long center bevel) |
Thickness | 0.71mm (2pt)、1.06mm (3pt) |
Height | 23.60mm (.929"), 23.80mm (.937") |
Angle | ∠42°、52° |
Body hardness | HV320,340,380,400,450 / HRC32,34,38,40,45 |
Edge hardness | HV600,640,670,700 / HRC55,58,59,60 |
Side Bevel Rule |
TYPE | S |
---|---|
Bevel type | SB (Side bevel) , LSB (Long Side bevel) |
Thickness | 0.71mm (2pt)、1.06mm (3pt)、1.42mm (4pt) |
Height | 23.60mm (.929"), 23.80mm (.937") |
Angle | ∠42°、51°、52° |
Body hardness | HV320,340,380,400,450 / HRC32,34,38,40,45 |
Edge hardness | HV600,640,670,700 / HRC55,58,59,60 |
Creasing Rule |
TYPE | E |
---|---|
Bevel type | DR (Double Round) / SR (Single Round) / SF (Special facet) |
Thickness | 0.71mm (2pt)、1.06mm (3pt)、1.42mm (4pt) |
Height | 22.80mm (.897"), 23.10mm(.909") |
Body hardness | HV320,340,380,400,450 / HRC32,34,38,40,45 |
