Hand tool
Hand tools are tools held and operated by people, requiring characteristics such as durability, functionality, comfort, precision, accuracy, safety, and maintainability. Commonly used steel grades include S50C, S65C, SK85, 1065, 1085, SCM series, and SKS series.
| Cr-Mo Steel | Chemical Conposion(%) | |||||||||
|---|---|---|---|---|---|---|---|---|---|---|
| JIS | Nippon steel | C | Si | Mn | P | S | Cu | Ni | Cr | Mo |
| SCM415 | 0.13 ~ 0.18 | 0.15 ~ 0.35 | 0.60 ~ 0.90 | ≦0.030 | ≦0.030 | ≦0.30 | ≦0.25 | 0.90 ~ 1.20 | 0.15 ~ 0.25 | |
| SCM435 | 0.33 ~ 0.38 | 0.15 ~ 0.35 | 0.60 ~ 0.90 | ≦0.030 | ≦0.030 | ≦0.30 | ≦0.25 | 0.90 ~ 1.20 | 0.15 ~ 0.30 |
| Cr Steel | Chemical Conposion(%) | |||||||||
|---|---|---|---|---|---|---|---|---|---|---|
| JIS | Nippon steel | C | Si | Mn | P | S | Cu | Ni | Cr | Nb |
| SCr420 | 0.18 ~ 0.23 | 0.15 ~ 0.35 | 0.60 ~ 0.90 | ≦0.030 | ≦0.030 | ≦0.30 | ≦0.25 | 0.90 ~ 1.20 | ||
| N50CRN | 0.50 ~ 0.55 | 0.15 ~ 0.35 | 0.65 ~ 0.85 | ≦0.010 | ≦0.010 | 0.40 ~ 0.60 | 0.20 ~ 0.35 |
| Cr-Mo Steel | Hardness | Tensile Strength (N/mm²) | ||
|---|---|---|---|---|
| JIS | Nippon steel | HV | HRC | |
| SCM415 | ~ 170 | ~ 545 | ||
| SCM435 | ~ 190 | ~ 605 |
| Cr Steel | Hardness | Tensile Strength (N/mm²) | ||
|---|---|---|---|---|
| JIS | Nippon steel | HV | HRC | |
| SCr420 | ~ 170 | ~ 545 | ||
| N50CRN | ~ 254 | ~ 795 |
RECOMMENDATION
Watercraft
Chromium molybdenum steel
Seat belt
Chromium molybdenum steel
Chain parts
Chromium molybdenum steel
